| Mechanical Specification | |
| Overall diameter (mm) | 156 |
| Depth (mm) | 65 |
| Net weight (kg) | 4 |
| Electrical Specification | |
| Nominal impedance (Ohms) | 8 |
| Throat Diameter(mm) | 38mm(1.5in) |
| Nominal power handling (W) | 100 |
| Program power (W) | 200 |
| Sensitivity (dB) (1w/1m) | 110 |
| Frequency range (Hz) | 1.0K-18K |
| Voice coil diameter (mm) | 75.4(3") |
| Voice coil material | ACCW |
| Diaphragm material | Titanium |
| Former material | Kapton |
| Magnet size(mm) | Y30,Φ156xΦ80x20 |
Specification
